H.264 Video Compression Technology: High compression ratio, convenient for transmitting high-definition images over narrow bandwidths.
Dual Stream Support:
Main Stream: 23041296, 19201080
Sub Stream: 704*576
Variable Bit Rate and Frame Rate Settings: Allows for setting video image quality while limiting video image compression bit rate.
Day/Night Color and Black/White Switching: Automatic ICR (Infrared Cut Remover) switching.
Supports Motion Detection and Network Fault Detection: Includes strategies and alarm recording.
Remote Monitoring via Browser and Mobile Phone: Simple cloud service remote access operations.
Supported Protocols: PPPoE, DHCP, TCP/IP, HTTP, UDP, RTP/RTCP, RTSP, UPNP, SMTP, FTP, SIP, DDNS, DNS.
Embedded Web Server: Supports video viewing, parameter configuration, upgrades, and user rights management via IE browser.
ONVIF Protocol Support: Compatible with ONVIF standards.
POE Power Supply Support: Customizable (optional).
| Category | Parameter | Specification |
| Video | Image Sensor | 1/3" Progressive Scan CMOS |
| Resolution | 3 Megapixels, 1920 x 1080 | |
| Video Scanning Method | Progressive Scanning | |
| Dual Filter | ICR (IR-CUT) Dual Filter | |
| Angle | Horizontal Angle: ~85°, Diagonal Angle: ~110° | |
| Minimum Illumination | Color: 0.05LUX@F1.2; B/W: 0LUX (IR On) | |
| Video Compression | H.264 @ 3.0 / MPEG-4 / MJPEG / JPEG | |
| Video Stream | Main Stream/Sub Stream | |
| Main Stream | 2304×1296, 1920×1080, 30fps | |
| Sub Stream | 704576, 640360, 352*288 | |
| Video Bitrate | 0.1Mbps～6Mbps (Adjustable) | |
| Network Function | On-Monitor | Supports channel name, date, video stream info; menu position adjustable |
| Storage Method | Manual, Automatic (Cycle, Timer, Alarm Trigger, Motion Detection) | |
| Network Protocol | Supports RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP | |
| Network Interface | 6 pole female aircraft connector (or RJ45 network interface + DC female) | |
| Heartbeat Function | Supported | |
| Watermark Function | Channel, Date-Time OSD Watermark Overlay | |
| Privacy Masking | Supported | |
| Password Protection | Three-Level Password Protection | |
| FTP Protocol | Supported | |
| RTSP Protocol | Supported | |
| PC Browser | Supports IE6.0 and above (Embedded Web Server), supports Firefox/Google/Apple browsers, supports 10 concurrent users (MAX) | |
| Mobile Platform | Supported (iPhone, Windows Mobile, BlackBerry, Symbian, Android) | |
| ONVIF Protocol | ONVIF National Standard Protocol, compatible with major NVR brands | |
| Cloud Service | P2P One-Click Remote Networking, Gateway Penetration Function | |
| POE | Supports External POE Function | |
| Supplementary Light | Infrared Light | 18 Infrared Lights |
| Infrared Distance | 15 meters | |
| Environmental | Operating Temperature | -20℃ ~ +60℃ |
| Operating Humidity | 0% - 90% | |
| Physical Specifications | Power Supply | DC12V (POE Power Supply) |
| Power Consumption | 15W (MAX) | |
| Protection Level | IP69K | |
| Dimensions | 108(W) x 78(H) x 75(D) mm |
*This product information is for reference only! If there is any change, the actual product shall prevail, the final interpretation right belongs to our company!
