Features:
Utilizes H.264 video compression technology, offering a high compression ratio, making it convenient for transmitting high-definition images over narrow bandwidths.
Supports dual streams: Main stream: 2304*1296, 1920*1080; Sub stream: 704*576.
Supports variable bit rate and frame rate settings, allowing the video image quality to be set while also limiting the video image compression bit rate.
Supports day/night color and black/white switching with automatic ICR (Infrared Cut Remover) switching.
Supports motion detection, network fault detection, and other strategies, as well as alarm recording.
Supports remote monitoring via browser and mobile phone, with simple cloud service remote access operations.
Supports PPPoE, DHCP, TCP/IP, HTTP, UDP, RTP/RTCP, RTSP, UPNP, SMTP, FTP, SIP, DDNS, DNS protocols.
Embedded Web Server, supports video viewing, parameter configuration, upgrades, and user rights management via IE browser.
Supports ONVIF protocol.
Can support POE (Power Over Ethernet) power supply (customizable).
| Category | Parameter | Specification |
| Video | Image Sensor | 1/3" Progressive Scan CMOS |
| Resolution | 3 Megapixels, 1920*1080P | |
| Video Scanning Method | Progressive Scanning | |
| Dual Filter | ICR (IR-CUT) Dual Filter | |
| Angle | Horizontal Angle: ~85°, Diagonal Angle: ~110° | |
| Minimum Illumination | Color: 0.05LUX@F1.2; B/W: 0LUX (IR On) | |
| Video Compression | H.264 @ 3.0 / MPEG-4 / MJPEG / JPEG | |
| Video Stream | Main Stream/Sub Stream | |
| Main Stream | 19201080 1-20fps, 1280720 1-30fps | |
| Sub Stream | 640*360 1-30fps | |
| Video Bitrate | 128Kbps-8192bps (Continuously Adjustable) | |
| Network Function | On-Screen Display | Supports channel name, date, video stream info; menu position adjustable |
| Storage Method | Manual, Automatic (Cycle, Timer, Alarm Trigger, Motion Detection) | |
| Network Protocol | Supports RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP | |
| Network Interface | 6-pin Aviation Head (or RJ45 Network Interface + DC Head) | |
| Watermark Function | Channel, Date-Time OSD Watermark Overlay | |
| Privacy Masking | Supported | |
| Password Protection | Three-Level Password Protection | |
| FTP Protocol | Supported | |
| RTSP Protocol | Supported | |
| PC Browser | Supports IE6.0 and above (Embedded Web Server), supports Firefox/Google/Apple browsers, supports 10 concurrent users (MAX) | |
| Mobile Platform | Supported (iPhone, Windows Mobile, BlackBerry, Symbian, Android) | |
| ONVIF Protocol | ONVIF National Standard Protocol, compatible with major NVR brands | |
| Cloud Service | P2P One-Click Remote Networking, Gateway Penetration Function | |
| POE | Supports External POE Function | |
| Supplementary Light | Infrared Light | 10 Infrared Lights |
| Infrared Distance | 5 meters | |
| Environmental | Operating Temperature | -20℃ ~ +60℃ |
| Operating Humidity | 0% - 90% | |
| Physical Specifications | Power Supply | DC12V (POE Power Supply) |
| Power Consumption | 15W (MAX) | |
| Protection Level | IP69K | |
| Dimensions | 74(W) x 64(H) x 56(D) mm |
*This product information is for reference only! If there is any change, the actual product shall prevail, the final interpretation right belongs to our company!
